Zero Halogen Polyolefin Heat Shrink Tube For Wire Harness Insulation Heat Shrink Sleeve

I'm Online Chat Now
Certification
China Shenzhen Tainy Electronic Co.,Ltd certification
China Shenzhen Tainy Electronic Co.,Ltd certification
I got it and already delivered to the customer who is happy. Hope to have some more business soon.

—— Nicolas

All samples look great!

—— Rob

Your material is good. I am happy to see 100% perfect matching material for us

—— Gang Won Lee

Your Material is good, I will arrange to order it soon.

—— Acosta

Nothing is impossible for a willing heart.

—— Mahajan

Zero Halogen Polyolefin Heat Shrink Tube For Wire Harness Insulation Heat Shrink Sleeve

Zero Halogen Polyolefin Heat Shrink Tube For Wire Harness Insulation Heat Shrink Sleeve
Zero Halogen Polyolefin Heat Shrink Tube For Wire Harness Insulation Heat Shrink Sleeve Zero Halogen Polyolefin Heat Shrink Tube For Wire Harness Insulation Heat Shrink Sleeve Zero Halogen Polyolefin Heat Shrink Tube For Wire Harness Insulation Heat Shrink Sleeve Zero Halogen Polyolefin Heat Shrink Tube For Wire Harness Insulation Heat Shrink Sleeve

Large Image :  Zero Halogen Polyolefin Heat Shrink Tube For Wire Harness Insulation Heat Shrink Sleeve Get Best Price

Product Details:
Place of Origin: china
Brand Name: no
Certification: UL224
Payment & Shipping Terms:
Minimum Order Quantity: 100meters
Price: Negotiate
Packaging Details: roll
Delivery Time: 3-5days
Payment Terms: Western Union, T/T, L/C,Paypal
Supply Ability: 50000meters per day
Detailed Product Description
Material: PE Shrink Ratio: 2:1
Size: 1.0~250mm Color: White/black/yellow/blue/green/yellow
High Light:

Polyolefin Cable Heat Shrink Tube

,

Zero Halogen Polyolefin Heat Shrink Tube

,

Wire Harness Insulation Heat Shrink Sleeve

Heat shrinkable tube , Color Heat Shrink Tube Tubing , PE shrinkable tube


Model Number: HS-125H
Working temperature: -45ºC ~ 125ºC

Structure
Halogen free flame-retardant heat shrinkable tube is made of eco-friendly cross-linking polyolefin material under irradiation. It has environment-friendly, flexible, flame retardant, quick shrink and stable performances. Also, it has electrical insulation, welding point anticorrosion and antirust and mechanical performances. It has passed UL, RoHS, Reach certifications for 300V and 600V.

Usage
It is mainly used in electronics, telecommunication, automobiles,shipping and other manufacturing industries.

Characteristics

  1. Halogen free, non-smoke, non-toxic, flame-retardant, soft, quick shrink, stable performance
  2. Shrink ratio: 2:1
  3. Shrink temperature: 84ºC ~ 120ºC
Property Unit Test Method Standard
Tensile Strength MPA ≥10.4(before aging) GB/T 1040
≥7.3(after aging) 158ºC*168h
Breakage Elongation (%) % ≥200(before aging) GB/T 1040
≥100(after aging) 158ºC*168h
Heat Shock - no sticking & no cracking 250ºC*4h
Cold Blend - no cracking -30ºC*4h
Breakdown Strength KV/mm ≥15 GB/T 1408
Dielectric Withstand 600V - Pass no breakdown for 2500V, 60s
300V - Pass no breakdown for 1500V,60s
Volume Resistivity Ω. cm ≥1×1014 GB/T 1410
Corrosion Performance - pass 158ºC*168h
Copper Stability - pass 158ºC*168h
Flammability - pass VW-1



Zero Halogen Polyolefin Heat Shrink Tube For Wire Harness Insulation Heat Shrink Sleeve 0Zero Halogen Polyolefin Heat Shrink Tube For Wire Harness Insulation Heat Shrink Sleeve 1

Zero Halogen Polyolefin Heat Shrink Tube For Wire Harness Insulation Heat Shrink Sleeve 2Zero Halogen Polyolefin Heat Shrink Tube For Wire Harness Insulation Heat Shrink Sleeve 3

Zero Halogen Polyolefin Heat Shrink Tube For Wire Harness Insulation Heat Shrink Sleeve 4

Zero Halogen Polyolefin Heat Shrink Tube For Wire Harness Insulation Heat Shrink Sleeve 5Zero Halogen Polyolefin Heat Shrink Tube For Wire Harness Insulation Heat Shrink Sleeve 6Zero Halogen Polyolefin Heat Shrink Tube For Wire Harness Insulation Heat Shrink Sleeve 7
