Wire Insulation Protection Coloured PVC Tubing VW-1 Sleeves ID 1.0mm - 30mm

Wire Insulation Protection Coloured PVC Tubing  VW-1 Sleeves ID 1.0mm - 30mm
Wire Insulation Protection Coloured PVC Tubing  VW-1 Sleeves ID 1.0mm - 30mm

Large Image :  Wire Insulation Protection Coloured PVC Tubing VW-1 Sleeves ID 1.0mm - 30mm Get Best Price

Product Details:
Place of Origin: China
Certification: SGS
Model Number: HCY-3
Working: -30˚C~105˚C
color: white/black/grey/silver/red/blue/pink/yellow
Application: All kinds of electrical appliances & industrial appliances
Payment & Shipping Terms:
Minimum Order Quantity: 1000meters
Price: Negotiate
Packaging Details: Roll
Delivery Time: 5-7days
Payment Terms: TT
Supply Ability: 50000meters /day
Detailed Product Description
Material: PVC Flammability: VW-1
Approval:: UL Tensile Strength (Mpa ):: ≥10.41
Highlight:

flexible pvc pipe

,

braided pvc tubing



Wire Insulation Protection Coloured PVC Tubing VW-1 PVC Sleeves​



Product  introduction:


Material: PVC


Working temperature: -30 ℃ ~ + 105 ℃;


Environmental standards: ROHS



Colors:White,red,pink,blue, black, transparent (color can be customized)


Product Features: Soft, has good electrical and physical properties, acid, corrosion resistance, stable performance, etc.



Size: ID: 1.0mm-30mm  Thickness:0.3mm~0.7mm

Applications: All kinds of electrical appliances, industrial appliances, lighting, automotive wiring harness, electronic components, motor leads, machinery, toys, stationery and other fields.



Technical Data:

Item Value
( ℃ ) cont inuous operating temperature -30~105
(Mpa)Tensile strength ≥10.4(1.5kgf/mm2)
(%)Ult imate elpong ion ≥100
Aging in circulating air oven (136.0±1.0) ℃,7days at 136.0±1.0℃



After aging

(Mpa)Tensile strength ≥7.28
(%)Ult imate elongat ion ≥70
(V)Pitential rating 300V,600V
(Ω.cm)Volume reslst ivity ≥10
(V)Potent ial rating ≥2500(60s) ≥2500(60s),no breakdown
Heat shock (105℃×4h) No cracking
Cold bend (-10℃) No cracking
Maximum iong longitudinal change ±5%
